DDPAI Z90 Master

Flagship multi-channel dash cam designed for maximum coverage and high-detail recording. The DDPAI Z90 Master combines 4K front, 4K rear and up to 3K cabin recording on supported three-channel configurations, with dual Sony STARVIS 2 IMX678 sensors on the front and rear cameras.

Highlights

• Up to 4K front + 4K rear + 3K interior recording on supported 3-channel configurations
• Dual Sony STARVIS 2 IMX678 image sensors on the front and rear cameras
• Triple HDR and IR interior-camera support on the three-channel system
• 5GHz Wi-Fi, BLE 5.1 and app control
• Supercapacitor power design
• GNSS support: GPS, BDS, GLONASS, Galileo and QZSS
• Optional 4G and parking-monitoring functions require the appropriate compatible hardware/service

Recording & optics

• Front: up to 3840×2160 at 30fps; optional 2880×1620 at 60fps
• Rear: up to 3840×2160 at 25fps
• Cabin: up to 2880×1620 at 30fps on supported 3-channel configuration
• Field of view: 135° front, 126° rear, 148° cabin
• Aperture: F1.75 front, F1.7 rear, F1.5 cabin

Storage & connectivity

The Z90 Master supports DDPAI's dual-storage architecture and microSD expansion up to 512GB. Built-in storage availability and capacity can vary by model/version, so the selected package should be checked before ordering.

Parking & connected features

Compatible configurations can add parking monitoring and 4G-connected functions. These features depend on the selected bundle, compatible DDPAI accessories, installation, network service and regional availability.

Choose your configuration

Bundle contents vary by selected option. Review the selected configuration before ordering, particularly if you need cabin recording, parking surveillance or connected 4G functions.
